Thermal Two-Part Hybrids
HLT2000
Solstice HLT series products are two-component cured-in-place dispensable gap fillers could be easily dispensed w/good thixotropic characteristics and low viscosity, provides the high compressibility and excellent long term reliability. (2.0 W/m·K)
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
Two-Part, Dispensable, Very Low Compression Force HLT series products are two-component, dispensable thermally conductive gels, which offer long-term reliability and superior softness. The enhanced bonding force between the polymer base and the filler minimizes oil separation issues in storage. Prior to curing, the material maintains good thixotropic characteristics and low viscosity to be easily dispensed.
Typical Applications
• Consumer electronics
• Telecommunications equipment
• Automotive electronics
• Memory & power modules
Features
• Low contact resistance
• Easily to dispense and rework
• High compressibility for low stress applications
• Long-term reliability
• Reduced oil separation
• No pump-out and cracking
Typical Applications
• Consumer electronics
• Telecommunications equipment
• Automotive electronics
• Memory & power modules
Features
• Low contact resistance
• Easily to dispense and rework
• High compressibility for low stress applications
• Long-term reliability
• Reduced oil separation
• No pump-out and cracking
Typical Properties
Physical Properties
- Color
- Part A: Yellow
- Part B: White
- Cure Schedule
- 10 hours at 25 °C
- 30 min at 100 °C
- Hardness
- 50 Shore00, Test Method ASTM D2240
- Shelf Life
- 6 months
- Specific Gravity
- 2.8, Test Method ASTM D792
- Viscosity
- 200000-350000 cps, Test Method ASTM D2196
- Format
- Gel
Thermal Properties
- Thermal Conductivity
- 2.0 W/m-K, Test Method ASTM D5470
- Thermal Impedance
- 0.66 °C·in²/W, 1 mm at 10 psi, Typical Value, Test Method D5470
General Information
- Application
- Automation
- Gap Filler
- Lighting Device
- Key Features
- Cost Effectiveness
- Typical Uses
- Consumer electronics
- Memory & power modules
- Telecommunications equipment
- Sub-segment
- ECU
- Industry
- Automotive
- Consumer Electronics
- Technology and Telecommunications
Physical Properties
- Color
- Part A: Yellow
- Part B: White
- Cure Schedule
- 10 hours at 25 °C
- 30 min at 100 °C
- Hardness
- 50 Shore00, Test Method ASTM D2240
- Shelf Life
- 6 months
- Specific Gravity
- 2.8, Test Method ASTM D792
- Viscosity
- 200000-350000 cps, Test Method ASTM D2196
- Format
- Gel
Thermal Properties
- Thermal Conductivity
- 2.0 W/m-K, Test Method ASTM D5470
- Thermal Impedance
- 0.66 °C·in²/W, 1 mm at 10 psi, Typical Value, Test Method D5470
General Information
- Application
- Automation
- Gap Filler
- Lighting Device
- Key Features
- Cost Effectiveness
- Typical Uses
- Consumer electronics
- Memory & power modules
- Telecommunications equipment
- Sub-segment
- ECU
- Industry
- Automotive
- Consumer Electronics
- Technology and Telecommunications
- Color : Part A: Yellow|Part B: White
- Thermal Conductivity : 2.0 W/m-K, Test Method ASTM D5470
- Thermal Impedance : 0.66 °C·in²/W, 1 mm at 10 psi, Typical Value, Test Method D5470
- Specific Gravity : 2.8, Test Method ASTM D792
- Cure Schedule : 10 hours at 25 °C|30 min at 100 °C
- Shelf Life : 6 months
- Viscosity : 200000-350000 cps, Test Method ASTM D2196
- Hardness : 50 Shore00, Test Method ASTM D2240
- Format : Gel
- Typical Uses : Consumer electronics|Memory & power modules|Telecommunications equipment
- Key Features : Cost Effectiveness
- Sub-segment : ECU
- Application : Automation|Gap Filler|Lighting Device
- Industry : Automotive|Consumer Electronics|Technology and Telecommunications
