Solstice® HFO Blends
Solstice® 454B - (R-454B)
Solstice® 454B (R-454B) is a non-ozone-depleting, zeotropic blend designed as a low GWP alternative to R-410A in comfort air cooling and reversible heating applications.
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
Solstice® 454B demonstrates improved efficiency and matching capacity to R-410A, with a GWP that’s 78% lower, minimizing redesign costs and capital expenditures. Solstice 454B (R-454B) is the most optimized R-410A replacement, providing easy conversion with minimal changes from a R-410A design.
Thanks to its high critical temperature and broader operating envelope in low evaporating temperatures, Solstice® 454B outperforms other refrigerant alternatives in normal and high ambient conditions in a variety of applications such as:
Thanks to its high critical temperature and broader operating envelope in low evaporating temperatures, Solstice® 454B outperforms other refrigerant alternatives in normal and high ambient conditions in a variety of applications such as:
- Direct expansion (DX) chillers
- Residential/light commercial air conditioning and heat pumps
- Commercial packaged systems
- Data center computer room air conditioning
Specifications
General Information
- Application
- Buildings - Chillers - Comfort Cooling and Heating
- Buildings - Residential/Light Commercial AC/Heat Pumps
- Buildings - Variable Refrigerant Flow (VRF) Systems
- Data Centers - Room and Precision Air Conditioning
- Industrial Process Refrigeration – Chillers: Low or Medium Temperature
- Disclaimer
- Although the information presented is believed to be accurate and reliable, user assumes all risks and liabilities related to the use of the products and/or information contained herein (including, but not limited to, risks relating to results, regulatory compliance and health, safety and environment). Information on potential applications for a product does not relieve the user from responsibility for ensuring that such use is approved in a particular country. Statements or suggestions concerning possible uses of a product are made without representation or warranty that any such use is free of patent infringement and are not recommendations to infringe any patent.
- ASHRAE Number
- R-454B
- Brand
- Solstice®
- Formula
- R-1234yf / R-32 (31.1% / 69.9%)
- Glide
- 1.5
- Refrigerant Class
- HFO Blend
- Refrigerant Type
- Zeotropic blend
- Replaces
- R-410A
- Substitutes
- R-410A
- Typical Lubricant
- POE
Physical Properties
- Appearance
- Colorless
- Composition
- R-32 / R-1234yf (68.9% / 31.1%)
- Critical Density
- 443.1 kg/m3
- Critical Pressure
- 52.7 bar
- Critical Volume
- 0.00226 m3/kg
- Liquid Density
- 996.5 kg/m3 at 25 °C
- Liquid Heat Capacity
- 1.80 kJ/kg·°K at 25 °C
- Liquid Thermal Conductivity
- 105.4 mW/m·°K at 25 °C
- Liquid Viscosity
- 114.8 µPa·sec at 25 °C
- Lower Flammable Limit
- 0.303 kg/m³
- Molecular Weight
- 62.6 kg/kmol
- Solubility in Water
- No data available
- Vapor Density
- 50.7 kg/m3 at 25 °C
- Vapor Heat Capacity
- 1.43 kJ/kg·°K at 25 °C
- Vapor Pressure
- 1515.9 kPa at 25 °C
- Vapor Thermal Conductivity
- 15.0 mW/m·°K at 25 °C
- Vapor Viscosity
- 12.8 µPa·sec at 25 °C
Temperature
- Boiling Point/Range
- -50.9 °C
- -59.62 °F
- Critical Temperature
- 170.6 °F / 77.0 °C
- Flashpoint
- Not applicable
Safety & Environment
- Flammable Range
- 11.25% (LFL), 22.00% (UFL)
- Global Warming Potential
- 467 rev /5TH IPCC
- Ozone Depletion Potential
- 0
Standards & Approvals
- ASHRAE Safety Classification
- A2L (Mildly flammable)
- REACH Product Stewardship
- Approved
General Information
- Application
- Buildings - Chillers - Comfort Cooling and Heating
- Buildings - Residential/Light Commercial AC/Heat Pumps
- Buildings - Variable Refrigerant Flow (VRF) Systems
- Data Centers - Room and Precision Air Conditioning
- Industrial Process Refrigeration – Chillers: Low or Medium Temperature
- Disclaimer
- Although the information presented is believed to be accurate and reliable, user assumes all risks and liabilities related to the use of the products and/or information contained herein (including, but not limited to, risks relating to results, regulatory compliance and health, safety and environment). Information on potential applications for a product does not relieve the user from responsibility for ensuring that such use is approved in a particular country. Statements or suggestions concerning possible uses of a product are made without representation or warranty that any such use is free of patent infringement and are not recommendations to infringe any patent.
- ASHRAE Number
- R-454B
- Brand
- Solstice®
- Formula
- R-1234yf / R-32 (31.1% / 69.9%)
- Glide
- 1.5
- Refrigerant Class
- HFO Blend
- Refrigerant Type
- Zeotropic blend
- Replaces
- R-410A
- Substitutes
- R-410A
- Typical Lubricant
- POE
Physical Properties
- Appearance
- Colorless
- Composition
- R-32 / R-1234yf (68.9% / 31.1%)
- Critical Density
- 443.1 kg/m3
- Critical Pressure
- 52.7 bar
- Critical Volume
- 0.00226 m3/kg
- Liquid Density
- 996.5 kg/m3 at 25 °C
- Liquid Heat Capacity
- 1.80 kJ/kg·°K at 25 °C
- Liquid Thermal Conductivity
- 105.4 mW/m·°K at 25 °C
- Liquid Viscosity
- 114.8 µPa·sec at 25 °C
- Lower Flammable Limit
- 0.303 kg/m³
- Molecular Weight
- 62.6 kg/kmol
- Solubility in Water
- No data available
- Vapor Density
- 50.7 kg/m3 at 25 °C
- Vapor Heat Capacity
- 1.43 kJ/kg·°K at 25 °C
- Vapor Pressure
- 1515.9 kPa at 25 °C
- Vapor Thermal Conductivity
- 15.0 mW/m·°K at 25 °C
- Vapor Viscosity
- 12.8 µPa·sec at 25 °C
Temperature
- Boiling Point/Range
- -50.9 °C
- -59.62 °F
- Critical Temperature
- 170.6 °F / 77.0 °C
- Flashpoint
- Not applicable
Safety & Environment
- Flammable Range
- 11.25% (LFL), 22.00% (UFL)
- Global Warming Potential
- 467 rev /5TH IPCC
- Ozone Depletion Potential
- 0
Standards & Approvals
- ASHRAE Safety Classification
- A2L (Mildly flammable)
- REACH Product Stewardship
- Approved
- Typical Lubricant : POE
- Refrigerant Class : HFO Blend
- Refrigerant Type : Zeotropic blend
- ASHRAE Number : R-454B
- Substitutes : R-410A
- Application : Buildings - Chillers - Comfort Cooling and Heating|Buildings - Residential/Light Commercial AC/Heat Pumps|Buildings - Variable Refrigerant Flow (VRF) Systems|Data Centers - Room and Precision Air Conditioning|Industrial Process Refrigeration – Chillers: Low or Medium Temperature
- Disclaimer : Although the information presented is believed to be accurate and reliable, user assumes all risks and liabilities related to the use of the products and/or information contained herein (including, but not limited to, risks relating to results, regulatory compliance and health, safety and environment). Information on potential applications for a product does not relieve the user from responsibility for ensuring that such use is approved in a particular country. Statements or suggestions concerning possible uses of a product are made without representation or warranty that any such use is free of patent infringement and are not recommendations to infringe any patent.
- Replaces : R-410A
- Formula : R-1234yf / R-32 (31.1% / 69.9%)
- Glide : 1.5
- Brand : Solstice®
- Liquid Thermal Conductivity : 105.4 mW/m·°K at 25 °C
- Vapor Thermal Conductivity : 15.0 mW/m·°K at 25 °C
- Lower Flammable Limit : 0.303 kg/m³
- Liquid Heat Capacity : 1.80 kJ/kg·°K at 25 °C
- Vapor Heat Capacity : 1.43 kJ/kg·°K at 25 °C
- Solubility in Water : No data available
- Critical Pressure : 52.7 bar
- Molecular Weight : 62.6 kg/kmol
- Liquid Viscosity : 114.8 µPa·sec at 25 °C
- Critical Density : 443.1 kg/m3
- Vapor Viscosity : 12.8 µPa·sec at 25 °C
- Critical Volume : 0.00226 m3/kg
- Vapor Pressure : 1515.9 kPa at 25 °C
- Liquid Density : 996.5 kg/m3 at 25 °C
- Vapor Density : 50.7 kg/m3 at 25 °C
- Composition : R-32 / R-1234yf (68.9% / 31.1%)
- Appearance : Colorless
- Critical Temperature : 170.6 °F / 77.0 °C
- Boiling Point/Range : -50.9 °C|-59.62 °F
- Flashpoint : Not applicable
- Ozone Depletion Potential : 0
- Global Warming Potential : 467 rev /5TH IPCC
- Flammable Range : 11.25% (LFL), 22.00% (UFL)
- ASHRAE Safety Classification : A2L (Mildly flammable)
- REACH Product Stewardship : Approved
