Foam Blowing Agents
Enovate® 245fa
Enovate® 245fa has been the standard in HFC technology for polyurethane foam applications worldwide. It offers proven insulating performance and excellent materials compatibility.
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
Solstice Enovate® 245fa blowing agent (HFC-245fa) is a proven replacement for HCFC-141b and other hydrofluorocarbon and nonfluorocarbon blowing agents in rigid polyurethane foam.
Solstice Enovate 245fa is:
Solstice Enovate 245fa is:
- Non-ozone-depleting
- Nonflammable (ASTM E-681, EU A11)
- Listed under the U.S. EPA’s Significant New Alternatives Policy (SNAP) program to replace ozone-depleting substances. (See the Environmental tab for more information)
- Listed on the TSCA inventory/registered under REACH
- VOC-exempt (per U.S. EPA)
- Manufactured in the U.S.
Specifications
General Information
- Application
- Liquified Natural Gas (LNG)
- PUR/PIR Foams
- Panels/Boardstock
- Refrigerator/Freezer Insulation
- Spray Foam Insulation
- ASHRAE Number
- 34
- Brand
- Enovate®
- Formula
- CF<sub>3</sub>CH<sub>2</sub>CHF<sub>2</sub>
- Linear Formula
- CF3CH2CHF2
- Replaces
- Other HFCs, HCFCs
Physical Properties
- Liquid Density
- 1.32 g/cc at 20°C
- Molecular Weight
- 134
- Solubility in Water
- 1600 ppm
- Vapor Pressure
- 123 kPa at 20 °C hectopascal
- 17.8 psia at 68 °F hectopascal
- Vapor Thermal Conductivity
- 0.0832 BTU in/ft2 hr at 25 °C
- 12.5 mW/mK at 25
Temperature
- Boiling Point/Range
- 15.3 °C
- 59.5°F
- Flashpoint
- None
- Freezing Point
- <-107 °C
- <-160 °F
Safety & Environment
- Flammable Range
- Non-flammable
- Global Warming Potential
- 858
- Ozone Depletion Potential
- 0
Standards & Approvals
- ASHRAE Safety Classification
- A2L
- REACH Product Stewardship
- Registered
General Information
- Application
- Liquified Natural Gas (LNG)
- PUR/PIR Foams
- Panels/Boardstock
- Refrigerator/Freezer Insulation
- Spray Foam Insulation
- ASHRAE Number
- 34
- Brand
- Enovate®
- Formula
- CF<sub>3</sub>CH<sub>2</sub>CHF<sub>2</sub>
- Linear Formula
- CF3CH2CHF2
- Replaces
- Other HFCs, HCFCs
Physical Properties
- Liquid Density
- 1.32 g/cc at 20°C
- Molecular Weight
- 134
- Solubility in Water
- 1600 ppm
- Vapor Pressure
- 123 kPa at 20 °C hectopascal
- 17.8 psia at 68 °F hectopascal
- Vapor Thermal Conductivity
- 0.0832 BTU in/ft2 hr at 25 °C
- 12.5 mW/mK at 25
Temperature
- Boiling Point/Range
- 15.3 °C
- 59.5°F
- Flashpoint
- None
- Freezing Point
- <-107 °C
- <-160 °F
Safety & Environment
- Flammable Range
- Non-flammable
- Global Warming Potential
- 858
- Ozone Depletion Potential
- 0
Standards & Approvals
- ASHRAE Safety Classification
- A2L
- REACH Product Stewardship
- Registered
- ASHRAE Number : 34
- Replaces : Other HFCs, HCFCs
- Linear Formula : CF3CH2CHF2
- Formula : CF3CH2CHF2
- Brand : Enovate®
- Application : Liquified Natural Gas (LNG)|PUR/PIR Foams|Panels/Boardstock|Refrigerator/Freezer Insulation|Spray Foam Insulation
- Vapor Thermal Conductivity : 0.0832 BTU in/ft2 hr at 25 °C|12.5 mW/mK at 25
- Vapor Pressure : 123 kPa at 20 °C hectopascal|17.8 psia at 68 °F hectopascal
- Solubility in Water : 1600 ppm
- Molecular Weight : 134
- Liquid Density : 1.32 g/cc at 20°C
- Freezing Point : <-107 °C|<-160 °F
- Flashpoint : None
- Boiling Point/Range : 15.3 °C|59.5°F
- Ozone Depletion Potential : 0
- Global Warming Potential : 858
- Flammable Range : Non-flammable
- REACH Product Stewardship : Registered
- ASHRAE Safety Classification : A2L
Technical Note
Name
Description
File Size
Date
Size
Step by step guide
application/pdf 761.92 KB
10/31/2023
761.92 KB
Step by step guide
application/pdf 872.51 KB
10/31/2023
872.51 KB
Read how trans-1-chloro-3,3,3-trifluoropropylene (tCFP, chemical formula CHCl=CHCF3) has been proposed as a potential substitute compound for currently used blowing agents with potential climate issues
application/pdf 849.73 KB
10/31/2023
849.73 KB
Instructions for preparing a rigid polyurethane foam hand mix
application/pdf 1.08 MB
10/31/2023
1.08 MB
Step by step guide
application/pdf 839.5 KB
10/31/2023
839.5 KB
