Medical Propellant
HFO-1234ze(E), GMP
As a near-zero global warming potential (GWP) propellant, our HFO-1234ze(E), GMP offers performance similar to HFC-134a and is a near drop-in replacement with only minimal changes required to equipment.
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
HFO-1234ze(E), GMP is a breakthrough for pressurized metered dose inhalers (pMDIs). A non-flammable and low global warming potential (GWP) alternative to hydrofluorocarbons, it is non-ozone-depleting, VOC-exempt (U.S. EPA and CARB), with an ultra-low GWP of less than 1.
Specifications
General Information
- Application
- Propellant
- ASHRAE Number
- 34
- Chemical Name
- trans-1,3,3,3-Tetrafluoropropene
- Formula
- CF3-CH=CHF
- Linear Formula
- CF<sub>3</sub>CH=CHF
- Synonyms
- HFO-1234ze (E), 1234ze(E), trans-1234ze
Physical Properties
- Critical Density
- 489 kg/m3
- Critical Pressure
- 36.36 bar
- Expansion Ratio
- 247 at 1 atm and 60 °F (15.6 °C) (Liquid to Gas)
- Kauri-Butanol Value
- 12.5
- Liquid Density
- 1.17 g/mL at 21 °C
- Liquid Expansion Coefficient
- 0.0017 at 60 °F (15.6 °C)
- Liquid Viscosity
- 0.20 cP at 25 °C
- Molecular Weight
- 114 g/mol
- Solubility in Water
- 373 ppm at 20 °C
- Specific Gravity
- 3.958 at 60 °F (15.5 °C)
- Surface Tension
- 8.95 mN / m
- Vapor Pressure
- 3.4 bar (49 psig) at 21 °C
Temperature
- Boiling Point/Range
- -19 °C at 1 atm
- Critical Temperature
- 109.4 °C
Safety & Environment
- Flammable Range
- Non-Flammable (ASTM E-681/ISO 10156)
- Global Warming Potential
- <1
- Ozone Depletion Potential
- 0
Standards & Approvals
- ASHRAE Safety Classification
- A2L
General Information
- Application
- Propellant
- ASHRAE Number
- 34
- Chemical Name
- trans-1,3,3,3-Tetrafluoropropene
- Formula
- CF3-CH=CHF
- Linear Formula
- CF<sub>3</sub>CH=CHF
- Synonyms
- HFO-1234ze (E), 1234ze(E), trans-1234ze
Physical Properties
- Critical Density
- 489 kg/m3
- Critical Pressure
- 36.36 bar
- Expansion Ratio
- 247 at 1 atm and 60 °F (15.6 °C) (Liquid to Gas)
- Kauri-Butanol Value
- 12.5
- Liquid Density
- 1.17 g/mL at 21 °C
- Liquid Expansion Coefficient
- 0.0017 at 60 °F (15.6 °C)
- Liquid Viscosity
- 0.20 cP at 25 °C
- Molecular Weight
- 114 g/mol
- Solubility in Water
- 373 ppm at 20 °C
- Specific Gravity
- 3.958 at 60 °F (15.5 °C)
- Surface Tension
- 8.95 mN / m
- Vapor Pressure
- 3.4 bar (49 psig) at 21 °C
Temperature
- Boiling Point/Range
- -19 °C at 1 atm
- Critical Temperature
- 109.4 °C
Safety & Environment
- Flammable Range
- Non-Flammable (ASTM E-681/ISO 10156)
- Global Warming Potential
- <1
- Ozone Depletion Potential
- 0
Standards & Approvals
- ASHRAE Safety Classification
- A2L
- Formula : CF3-CH=CHF
- Linear Formula : CF3CH=CHF
- Chemical Name : trans-1,3,3,3-Tetrafluoropropene
- ASHRAE Number : 34
- Application : Propellant
- Synonyms : HFO-1234ze (E), 1234ze(E), trans-1234ze
- Liquid Expansion Coefficient : 0.0017 at 60 °F (15.6 °C)
- Solubility in Water : 373 ppm at 20 °C
- Kauri-Butanol Value : 12.5
- Critical Pressure : 36.36 bar
- Specific Gravity : 3.958 at 60 °F (15.5 °C)
- Molecular Weight : 114 g/mol
- Liquid Viscosity : 0.20 cP at 25 °C
- Critical Density : 489 kg/m3
- Surface Tension : 8.95 mN / m
- Expansion Ratio : 247 at 1 atm and 60 °F (15.6 °C) (Liquid to Gas)
- Vapor Pressure : 3.4 bar (49 psig) at 21 °C
- Liquid Density : 1.17 g/mL at 21 °C
- Critical Temperature : 109.4 °C
- Boiling Point/Range : -19 °C at 1 atm
- Ozone Depletion Potential : 0
- Global Warming Potential : <1
- Flammable Range : Non-Flammable (ASTM E-681/ISO 10156)
- ASHRAE Safety Classification : A2L
